Application Scope
Pavement Grooving machine is mainly used for asphalt pavement, cement road surface, large area ground surface crack of slot.
Features and Advantages
1.Pavement Grooving machine with small size, light weight, easy to operate, with itself power, don't have
to worry about the outside power supply and field construction.
2.Grooving machine can easily, precisely and quickly groove a 1-5 cm width, depth of the sealing slot 0 to 3 cm
in the asphalt and concrete pavement along any seam.
Specification
Model GYK-300 Engine Model KOHLER CH680 Diameter of Blade 120 Thickness of Blade 10 Qty of Blade 6 Rotating Speed(RPM/min) 3600 Grooving Depth(mm) 0-50 Grooving Width(mm) 8-10 Cutting Speed 5-10m/min Overall Dimension 1760*790*1100 Shipping Size 1780*800*1120 Weight(KG) 260 Shipping Weight(KG) 280 Volume of fuel tank(L) 25 Starting Method Electrical starting
