Features
1.Hydraulic machinery walk-behind;
2.Engine: American Kohler CH440, electric start 3600/14 horsepower;
3.Battery circuit: all cars equipped with 12V DC voltage generator 18 amps;
4.Optional laser system: US Tianbao, Germany MOBA + Leica;
5.Drive system: Hydraulic Italy Sam hydraulic SAM HYDRAULIC imported hydraulic drive motor;
6.Walking Control: Manual adjustment, mechanical proportional hydraulic valve;
7.Standard tires: 80/100 × 21 motorcycle tire choice AT28 × 10.00-12 ATV tires;
8.Suspension: Independent hydraulic suspension system;
Specification
Model
GYL-P300
GYL-E300
Engine Type
Kohler CH440
Kohler CH440
Power Kw(hp)
10.3/14.0
10.3/14.0
Weight(lbs)
398(876)
398(876)
Oil Tank Capacity(L)
14
14
Screed Head Width(m)
3.0
3.0
Self Propel
Standard
Standard
Electric Starter
Standard
Standard
Auto Level
Standard
Standard
Laser System
US Trimble,German MOBA+Leica,or Topcon
German MOBA+Leica
Drive Unit
Italy SAM hydraulic motor
Hydraulic motor
Main Pump
German REXROTH axial piston pump
High performance axial piston pump
Filters
Italy OMT high-precision filters
high-precision filters
Master Valve
Sauer-danfoss main control valve
Load sensitive pressure compensated main control valve
Vibration Control System
US INDCOM high-speed hydraulic motor
Chinese high-speed hydraulic motor
Accumulator
German HYDAC high-pressure accumulator
high-pressure accumulator
Hydraulic Hose
US GATES high-pressure hose
High-pressure resistance Hose
